PCB Spring-cage terminal blocks Home >PCB Spring-cage terminal blocks

SD

Detail


Technical data 技术数据

                                              Approval  cULus  VDE

Technical data(UL/cUL) UL认证数据(UL/cUL)        Use Group应用组别BCD
Nominal voltage (V) 额定电压(V)150--
Nominal current (A) 额定电流(A)6--
Connection capacity(AWG) 接线容量(AWG)26-18--










Technical data in accordance with IEC and VDE  技术数据，符合IEC/DIN VDE标准
Rated insulation voltage at pollution degree 2(V)额定电压/污染等级2160
Rated current/conductor cross-section (A/mm2) 额定电流/接线容量4/0.5
Solid/stranded(mm2) 单芯线（刚性）/多芯线（柔性）-
Surge voltage category/pollution degree 浪涌电压类别/污染等级III/3III/2II/2
Rated insulation voltage(V) 额定电压63160320
Rated surge voltage(kV) 额定浪涌电压2.52.52.5











Genenral data  一般参数
Stripping length(mm) 剥线长度9-10
Insulation material group 绝缘材料类型/材料组别PA66/I
Inflammblility class acc. to UL94 阻燃等级，符合UL94标准V0
Borehole diameter/pin dimensions PCB钻孔尺寸/针脚尺寸1.2/0.4*0.8
