Technical data 技术数据 Approval cULus VDE | |||
| Technical data(UL/cUL) UL认证数据(UL/cUL) Use Group应用组别 | B | C | D |
| Nominal voltage (V) 额定电压(V) | 300 | - | 300 |
| Nominal current (A) 额定电流(A) | 15 | - | 10 |
| Connection capacity(AWG) 接线容量(AWG) | 24-12 | - | 24-12 |
| Technical data in accordance with IEC and VDE 技术数据，符合IEC/DIN VDE标准 | |||
| Rated insulation voltage at pollution degree 2(V)额定电压/污染等级2 | 250 | ||
| Rated current/conductor cross-section (A/mm2) 额定电流/接线容量 | 24/2.5 | ||
| Solid/stranded(mm2) 单芯线（刚性）/多芯线（柔性） | 0.5-4/0.5-2.5 | ||
| Surge voltage category/pollution degree 浪涌电压类别/污染等级 | III/3 | III/2 | II/2 |
| Rated insulation voltage(V) 额定电压 | 250 | 320 | 630 |
| Rated surge voltage(kV) 额定浪涌电压 | 4 | 4 | 4 |
| Genenral data 一般参数 | |||
| Stripping length(mm) 剥线长度 | 6-7 | ||
| Screw thread 螺纹规格 | M2.5 | ||
| Tightening torque(Nm) 最大紧固扭矩 | 0.4 | ||
| Insulation material group 绝缘材料类型/材料组别 | PA66/I | ||
| Inflammblility class acc. to UL94 阻燃等级，符合UL94标准 | V0 | ||
