PCB Barrier Screw terminal blocks

Product details


Technical data 技术数据

                                              Approval  cULus

Technical data(UL/cUL) UL认证数据(UL/cUL)        Use Group应用组别BCD
Nominal voltage (V) 额定电压(V)300-300
Nominal current (A) 额定电流(A)15-10
Connection capacity(AWG) 接线容量(AWG)22-14-22-14










Ohter technical data 其它技术数据
Withstand voltage 耐高压1.6KV/1min
Insulation resistance (/DC) 绝缘阻抗(兆欧/直流)1000/DC 500V
Termperature stability 产品操作温度-40 ºC to 115 ºC
Soldering temperature 产品波峰焊接温度250 ºC +/-5ºC








Genenral data  一般参数
Stripping length(mm) 剥线长度7-8
Screw thread 螺纹规格#6-32
Tightening torque(Nm) 最大紧固扭矩1.15
Insulation material group 绝缘材料类型/材料组别PA66/I
Inflammblility class acc. to UL94 阻燃等级,符合UL94标准V0
