PCB Barrier Screw terminal blocks

Product details


Technical data 技术数据

Approval  cULus

Technical data(UL/cUL) UL认证数据(UL/cUL) Use Group应用组别 B C D
Nominal voltage (V) 额定电压(V) 300 - 300
Nominal current (A) 额定电流(A) 15 - 10
Connection capacity(AWG) 接线容量(AWG) 22-14 - 22-14










Ohter technical data 其它技术数据
Withstand voltage 耐高压 1.6KV/1min
Insulation resistance (/DC) 绝缘阻抗(兆欧/直流) 1000/DC 500V
Termperature stability 产品操作温度 -40 ºC to 115 ºC
Soldering temperature 产品波峰焊接温度 250 ºC +/-5ºC








Genenral data  一般参数
Stripping length(mm) 剥线长度 6-7
Screw thread 螺纹规格 M3.0
Tightening torque(Nm) 最大紧固扭矩 1.8
Insulation material group 绝缘材料类型/材料组别 PC/I
Inflammblility class acc. to UL94 阻燃等级,符合UL94标准 V0
